Electrical data
Nominal voltage
AC 230 V
Nominal voltage frequency
50/60 Hz
Nominal voltage range
AC 85…265 V
Power consumption in operation
6 W
Power consumption in rest position
2 W
Power consumption for wire sizing
11 VA
Connection supply / control
Cable 1 m, 3 x 0.75 mm²
Parallel operation
No
Functional data
Torque motor
Max. 90 Nm (not constant)
Manual override
with push-button, can be locked
Running time motor
35 s / 90°
Sound power level motor
35 dB(A)
Position indication
Yes
Safety
Protection class IEC/EN
II reinforced insulation
Degree of protection IEC/EN
IP66
EMC
CE according to 2014/30/EU
Low voltage directive
CE according to 2014/35/EU
Certification IEC/EN
IEC/EN 60730-1 and IEC/EN 60730-2-14
Mode of operation
Type 1
Rated impulse voltage supply / control
2.5 kV
Control pollution degree
4
Ambient temperature
-30…50°C
Ambient temperature note
-40…50°C for actuator with integrated heating
Non-operating temperature
-40…80°C
Ambient humidity
100% r.H.
Maintenance
Maintenance-free
Mechanical data
Connection flange
F07
Weight
Weight
5.8 kg
