Flow medium SS304 disc: cold and warm water. Max. 50% Glycol
Temperature of medium SS304 disc: Cold water and warm
Nominal pressure 1600kPa (PN16)
Leakage rate Rate A Bubble tight (ISO 5208)
Pipe connections ISO 7005.2 PN16 wafer (U type flange)
Max. Close-off pressure 1000kPa (DN700…1200)
Installation position Vertical to horizontal
Maintenance Maintenance-free
Angle of rotation 90° rotation
Valve Material
Body
Disc
Seat
Stem
Ductile cast iron GGG40 (DN700…1200)
Stainless steel 304 disc
EPDM
Stainless steel 420
