Electrical data Nominal voltage AC 24V, 50/60 Hz / DC 24V
Nominal voltage range AC 19.2…28.8V / DC 21.6…28.8V
Power consumption In operation
At rest
For wire sizing
11W @ nominal torque
3W
21VA (lmax 20A @ 5ms)
Connection Cable 1m, 2 x 0.75mm²
Parallel operation Yes (note the performance data)
Functional data Torque min. 40Nm @ nominal voltage
Emergency setting position (POP) NC / NO
Position accuracy ±5%
Manual override Gearing latch disengaged with push button
Running time Motor
Emergency setting
function
150s / 90°
35s @ 0…50°C
Sound power level Motor
Emergency setting
function
≤52dB(A) @ 150s
≤61dB(A)
Position indication Mechanical
Safety Protection class III Safety extra-low voltage
UL Class 2 Supply
Degree of protection IP54
NEMA 2, UL Enclosure Type 2
EMC CE according to 2004/108/EC
Certification Certified to IEC/EN 60730-1 and IEC/EN
60730-2-14
Principle of operation Type 1.AA
Rated impulse voltage 0.8kV
Control pollution degree 3
Ambient temperature –30…+50°C
Non-operating temperature –40…+80°C
Ambient humidity 95% r.h., non-condensing
Maintenance Maintenance-free
Mechanical data Connection flange F07
Dimensions / Weight Dimensions See «Dimensions»
Weight Approx. 2.8kg
