Electrical data Nominal voltage AC/DC 24 V
Nominal voltage frequency 50/60 Hz
Nominal voltage range AC 19.2…28.8 V / DC 21.6…28.8 V
Power consumption in operation 2.5 W
Power consumption in rest position 0.5 W
Power consumption for wire sizing 5 VA
Connection supply / control Terminals with cable 1 m, 3 x 0.75 mm²
(Terminal 4 mm²)
Parallel operation Yes (note the performance data)
Functional data Actuating force motor 1500 N
Manual override with push-button, can be locked
Stroke 20 mm
Running time motor 150 s / 20 mm
Sound power level, motor 35 dB(A)
Position indication Mechanically, 5…20 mm stroke
Safety Protection class IEC/EN III Safety Extra-Low Voltage (SELV)
Protection class UL UL Class 2 Supply
Degree of protection IEC/EN IP54
Degree of protection NEMA/UL NEMA 2
Enclosure UL Enclosure Type 2
EMC CE according to 2014/30/EU
Certification IEC/EN IEC/EN 60730-1 and IEC/EN 60730-2-14
Certification UL cULus according to UL60730-1A, UL60730-2-
14 and CAN/CSA E60730-1:02
Certification UL note The UL marking on the actuator depends on the
production site, the device is UL-compliant in
any case
Mode of operation Type 1
Rated impulse voltage supply / control 0.8 kV
Control pollution degree 3
Ambient temperature 0…50°C
Storage temperature -40…80°C
Ambient humidity Max. 95% r.H., non-condensing
Servicing maintenance-free
Weight Weight 1.2 kg
