Electrical data Nominal voltage AC/DC 24V
Nominal voltage frequency 50/60Hz
Nominal voltage range AC 19.2…28.8V / DC 21.6…28.8V
Power consumption in operation 0.5W
Power consumption for wire sizing 1VA
Connection supply / control Cable 1m, 3 x 0.75mm²
Parallel operation Yes (note the performance data)
Functional data Torque motor Min. 2Nm
Positioning signal Y DC (0)2…10V
Positioning signal Y note Input impedance 100kΩ
Operating range Y DC 2…10V
Control operating range Y note for 0…100% (0…90°)
Manual override Gear disengagement with push-button
Running time motor 90s / 90°
Sound power level motor max. 35dB(A)
Position indication Mechanical
Safety Protection class IEC/EN III Safety extra-low voltage
Degree of protection IEC/EN IP40
EMC CE according to 2004/108/EC
Certification IEC/EN IEC/EN 60730-1 and IEC/EN 60730-2-14
Mode of operation Type 1
Rated impulse voltage supply / control 0.8kV
Control pollution degree 3
Ambient temperature -7…50°C
Non-operating temperature -40…80°C
Ambient humidity 95% r.h., non-condensing
Maintenance Maintenance-free
Weight Weight Approx. 0.4kg
