Service:Air and non-combustible, compatible gases.Wetted Materials:Consult factory.Accuracy:±0.25 FS @ 77°F (25°C).Thermal Effect:±0.02% FS/°F (0.036% FS/°C).Stability:±1% FS/yr.Temperature Limits:14 to 185°F (-10 to 85°C).Pressure Limits:See chart on catalog page.Power Requirements:10 to 35 VDC (2-wire); 17 to 36 VDC, or isolated 21.6 to 33 VAC (3-wire).Output Signal:4 to 20 mA (2-wire); 0 to 10 VDC (3-wire).Zero and Span Adjustments:Push buttons.Loop Resistance:Current output: 0 to 1250 Ω max; Voltage output: Load resistance 1 kΩ min.Current Consumption:40 mA max.Electrical Connections:Screw-type terminal block.Process Connections:1/8″ female NPT. Accessories included are 2 barbed fittings for 1/8″ (3.12 mm) and 3/16″ (4.77 mm) ID rubber or vinyl tubing.Mounting Orientation:Vertical, on a 1.378″ (35 mm) DIN rail.Weight:4.8 oz (136 g).Agency Approvals:CE.
