Service:Non-combustible liquid, gas, or vapor.Wetted Materials:17-4 PH Stainless Steel.Accuracy:RSS* (at constant temperature) ±0.25%. Non-linearity (BSFL) ±0.22% FS; Hysteresis 0.10% FS; Non-repeatability 0.05% FS.Temperature Limits:-40 to 185°F (-40 to 85°C).Compensated Temperature Range:-40 to 176°F (-40 to 80°C).Pressure Limits:2X max range.Thermal Effects:Zero Shift: ±2.0% FS/100°F (±1.8% FS/50°C); Span Shift: ±1.5% FS/100°F (±1.3% FS/50°C); Warm-up Shift: ±0.1% FS total.Stability:0.5% FS/year.Response Time:5 ms.Power Requirements:9-30 VDC.Output:4-20 mA**, 2-wire.Zero and Span Adjustment:Fixed.Loop Resistance:0 to 800 Ω.Shock:200 g.Vibration:20 g.Electrical Connections:2 ft (61 cm) multiconductor cable. Conduit Models: 1/4″-18 (22.3 mm) knockout.Enclosure:Stainless Steel and Valox.Weight:2.3 oz (65 g).Agency Approvals:CE.
*RSS of non-linearity, hysteresis, and non-repeatability.
**Zero output factory set to within ±0.16 mA; Span (full scale) output factory set to within ±0.16 mA.
