GAGE SPECIFICATIONSService:Compatible, non-combustible liquids & gases.Wetted Materials:17 to 4 stainless steel sensor, 316 SS socket.Housing Materials:Fiberglass reinforced thermoplastic case.Accuracy:0.25% FS (includes linearity, hysteresis, repeatability).Pressure Limit:2 x FS range.Process Connection:1/2″ male NPT.Display:5 digit (0.88″ high).
TRANSMITTER SPECIFICATIONSPower Requirements:12 to 36 VDC (loop powered).Memory Back Up Supply:(2) C alkaline batteries, installed functional, user replaceable.Output Signal:4 to 20 mA.Response Time:100 ms.Temperature Limits:14 to 140ºF (-10 to 60ºC).Thermal Effects:0.04% FS/°F.Electrical Connections:3 ft flying leads.Loop Resistance:DC; 0 to 1090 Ω max.Set Point Adjustments:Adjustable through menu selections.Weight:1.45 lb (.66 kg).Agency Approvals:CE.
