Service:Compatible liquids and gases.Wetted Materials:316L SS.Housing:Polycarbonate.Accuracy:±1% of FS including linearity, hysteresis, and repeatability (indicator and transmitter).Stability:< ±2% of FS per year.Pressure Limits:1.5 x range.Temperature Limits:Ambient: 20 to 140°F (-6.6 to 60°C); Process: 0 to 176°F (-18 to 80°C).Compensated Temperature Limits:32 to 122°F (0 to 50°C).Thermal Effect:±0.05% of F.S./°F.Display:4-digit backlit LCD (Digits: 0.60″H x 0.33″W).Power Requirements:12 to 30 VDC/AC.Power Consumption:2.5 watts.Electrical Connections:Removable terminal blocks with two 1/2″ female NPT conduit connections.Enclosure Rating:Meets NEMA 4X (IP65).Warm Up Time:<10 seconds.Mounting Orientation:Any position.Weight:1.18 lbs (535 g).Agency Approvals:CE, UL.
SWITCH SPECIFICATIONS:Switch Type:2 SPDT relays.Electrical Rating:5 A @ 120/240VAC, 1 A @ 30 VDC.Repeatability:±1% of FS (switching only).Set Points:Adjustable 0-100% of FS.Switch Indication:External LED for each relay on the front panel.Switch Reset:Manual or Automatic.
TRANSMITTER SPECIFICATIONS:Output Signal:4-20 mA, 1-6 VDC, 1-5 VDC, 0-5 VDC, or 0-10 VDC (direct or reverse output selection).Minimum Excitation:14 VDC.Zero and Span Adjustments:Menu scalable within the range.
