Accuracy:±3°F (±1.7°C).Temperature Limits:Operating: -40 to 302°F (-40 to 150°C).
Sensor Curves:Pt100 RTD (TE Series Curve D).
TEMPERATURE TRANSMITTER
Input Range:-328 to 986°F (-200 to 530°C).Output:Two-wire 4 to 20 mA.
Output Impedance:600 Ω @ 24 VDC.Power Requirements:12 to 35 VDC.
Accuracy:±0.2% FS.Temperature Limits:-40 to 185°F (-40 to 85°C).Response Time:<100 ms.
ENCLOSURE
Temperature Limits:-40 to 212°F (-40 to 100°C).Rating:NEMA 4X (IP65).Material:Painted aluminum housing.
