Action On/Off
Type of Motor Synchronous Stall
Supply Voltage (50/60 Hz)
VA-7010-8001: 24 VAC, Class 2, ±10%
VA-7010-8002: 120 VAC, ±10%
VA-7010-8003: 230 VAC, ±10%
VA-7010-8006: 208 VAC, ±10%
Power Consumption 7 VA
Minimum Force 20.2 lb (90 N)
Nominal Stroke 0.12 in. (3 mm), Maximum 0.2 in. (5 mm)
Full Stroke Time On Nominal 10 Seconds
Full Stroke Time Off Nominal 5 Seconds
Protection IP40, NEMA 1
Ambient Operating Conditions 35 to 122°F (2 to 50°C), Non-Condensing
Ambient Storage Conditions -4 to 149°F (-20 to 65°C), Non-Condensing
Electrical Connections 18 AWG, 20 in. (508 mm) Long Wire Leads
Shipping Weight 1.1 lb (0.5 kg)
Agency Listings
UL 873 Listed, File E27734, Guide XAPX, Plenum Rated
CSA C22.2 No. 139 Certified, File LR85083, Class 3221 01
CE Conformity VA-7010-8001:EMC Directive (89/336 EU)
