Display Backlighted graphical LCD
Size : 85 x 51 mm
Resolution : 240 x 180 pixels
Measuring ports connection Ribbed connectors Ø 4×7 mm tubes
Generation ports connection Quick-coupling connectors DN2.7
Power supply 100 – 240 Vac ±10% / 50-60 Hz or on batterry
Consumption 19 W
Battery life 8 hours
PC interface USB
Operating temperature From 0 to + 50° C
Storage temperature From -10 to + 70° C
Environment Air, non-aggressive gases, non-corrosive gases
Languages French, English
Weight 4.5 kg
Conformity EMC 2004/108/CE and EN 61010-1 directives
Fuse on the phase and on the neutral Time delay 1 A 250 V
Instrument to connect to earth protection
TECHNICAL FEATURES IN PRESSURE MEASUREMENT AND PRESSURE
