SPECIFICATIONS
Maximum Reading: 99,999
Cable Length: 50 cm extends to 1.5 m (20″ extends to approx. 5′)
Vane Diameter: 74 mm (2.9″)
Vane Size (H x W x D): 164 x 74 x 40 mm (6.45 x 2.9 x 1.57″)
Unit Size (H x W x D): 157 x 62 x 28 mm (6.18 x 2.44 x 1.1″)
Display Size (H x W): 34 x 47 mm (1.3 x 1.85″)
Digit Height: 18 mm (0.7″)
Display: High-contrast 5-digit display
Power: 4 “AAA” batteries (included)
Weight: 263 g (9.28 oz) without batteries
Response Time: 1 second
Operating Current: 5 to 8 mA
Operating Temperature: 0 to 50°C (32 to 122°F)
Operating Humidity: Less then 90% RH
Measurement Range Resolution Accuracy
Air Velocity 0.3 to 35 m/s
(1 to 114 ft/s) 0.1 ±5% FS
Air Volume 0 to 99,999 m³/min
(0 to 99,999 ft³/min) 0.1 ±5% FS
Capacity 0 to 99,999 BTU/h
(0 to 99,999 kW) 0.1 ±3% FS
Temperature -20 to 60 °C
(-4 to 140°F) 0.1° ±0.6°C (1°F)
Humidity 0 to 100% 0.1% ±3% FS from 10 to 90%
±5% FS above 90%
Dew Point -68 to 70°C
(-90 to 158°F) 0.1° ±3% FS from 10 to 90%
±5% FS above 90%
Wet Bulb -22 to 70°C
(-7.6 to 158°F) 0.1° ±3% FS from 10 to 90%
±5% FS above 90%
