PN class:PN 16
Operating voltage:AC 24 V
Power consumption:120 VA
Operating range:DC 0…10 V
Positioning signal:DC 0…10 V, DC 4…20 mA
Positioning time:Close:2 s
Spring return function:1->3 closed
Position feedback:DC 0…10 V
Degree of protection:IP31
Ambient temperature, operation:2…50 °C
Mounting position:Upright to horizontal
Leakage rate:0.05 % of kvs
Leakage rate bypass:2 % of kvs
Medium temperature:2…120 °C; 35…248 ºF
Medium:Water
Valve characteristic:Linear
Stroke resolution ΔH/H100:1:1000
Material, valve body:EN-GJL-HB215
Material, inside set:CrNi steel/brass
Δpmax:200 kPa
Δps:200 kPa
kvs:130 m³/h
DN:100
