PN class：PN 16
Operating voltage：AC 24 V, DC 24 V
Power consumption：65 VA
Operating range：DC 0…10 V, 0…20 mA, DC 2…10 V, 4…20 mA
Positioning signal：DC 0…10 V, DC 2…10 V, DC 0…20 mA, DC 4…20 mA, DC 0…20 V Phs
Positioning time：2 s
Spring return function：A-> AB closed
Position feedback：DC 0…10 V, DC 2…10 V, DC 0…20 mA, DC 4…20 mA
Degree of protection：IP31
Ambient temperature, operation：-5…45 °C
Mounting position：Upright to horizontal
Permissible operating pressure：Liquid, max: 1300 kPa; Steam, max: 900 kPa
Leakage rate：0.05 % of kvs
Absolute pressure p1 steam：900 kPa abs
Medium temperature：1…180 °C; 34…356 ºF
Medium：Steam , Water
Valve characteristic：Equal-percentage , Linear
Stroke resolution ΔH/H100：1:1000
Material, valve body：Nodular cast iron EN-GJS-400-18-LT
Material, inside set：CrNi steel
Δpmax：1000 kPa
Δps：1000 kPa
Dimensions (W x H x D)：254 x 531.5 x 165 mm
kvs：30 m³/h
DN：50
