PN class:PN 16
Operating voltage:AC / DC 24 V
Power consumption:29 VA
Positioning signal:DC 0…10 V, DC 2…10 V, DC 4…20 mA
Positioning time:<2 s
Spring return function:A->AB closed
Position feedback:DC 0…10 V
Degree of protection:IP54
Ambient temperature, operation:-5…45 °C
Mounting position:Upright to horizontal
Permissible operating pressure:1000 kPa
Leakage rate:< 0.02 % of kvs value
Leakage rate bypass:< 0.2 % of kvs value
Medium temperature:1…130 °C
Valve characteristic:Equal-percentage , Linear
Stroke resolution ΔH/H100:1:1000
Material, valve body:Cast iron EN-GJL-250
Material, inside set:CrNi steel/brass
Δpmax:300 kPa
Δps:300 kPa
kvs:3 m³/h
DN:15
