Operating voltage:AC 24 V, DC 16…33 V
Current consumption:<4 mA
Analog output, signal:DC 0…10 V
Time constant:<2 ms
Pressure conneciton:Internal thread UNF7/16-20
Connection cable:3-wire
Cable length:1.5 m
Connection, electrical:Cable
Medium temperature:-40…135 °C
Max. permissible pressure:3 x scale end value (FS)
Mounting position:Any
Measuring range, pressure:-1…9 bar, -100…900 kPa
Degree of protection:IP67
Dimensions (W x H x D):24 x 24 x 68 mm
Dimension (Ø x L):24 x 68 mm
