Operating voltage:AC 230 V
Frequency:50/60 Hz
Power consumption:12 VA
Control algorithm:PI
Communication:Bus: KNX (S-mode and LTE mode) , Room unit: PPS2
Service plug:RXT20.1
Digital inputs, number:2
Relay outputs, number:3
Relay outputs:For 3-speed fan control
Relay output, switching voltage:AC 250 V
Relay output, switching current:5 (4) A
Triac outputs, number:4
Triac outputs:PWM , 3-position
Triac output, switching voltage::AC 24 V
Triac output, switching current:0.5 A
Interface type:KNX-bus
Mounting:On DIN rail , With screws
Mounting location:Fan coil , Ceiling voids with cover , Panel
Dimensions (W x H x D):113 x 167 x 62 mm
Degree of protection:IP30
Product conformity:eu.bac certified
