Size 10.2 inches
Touch panel TFT LCD, LED backlight
Display color 65535 true color
Resolution 800 x 480 pixels
Screen brightness 200 cd/m2
Power supply DC 24 V
Rated power 15 W
CPU mainboard ARM CPU，400 MHz
RAM 64 M
Product
features
Storage device 128 M FLASH
Operating temperature 0°C to 45°C
Environment Operating humidity 5% to 90% RH
Storage temperature -10°C to 60°C
RS485 9600 bps, Modbus RTU, no parity
Interfaces USB Master and Slave
Ethernet Not supported
Certification CE
Certifications Protection class IP65 (front panel)
